C11000 ETP COPPER / ELECTRICAL & THERMAL CONDUCTIVITY

Pure Copper Balls

High-conductivity, non-magnetic copper spheres for electrical contacts, thermal systems, plating, art, research and specialty assemblies.

Request a Quote ↗Contact SDBALLS U.S.

Pure Copper Balls supplied by SDBALLS — PRODUCT REFERENCE / FINAL SPECIFICATION BY QUOTATION

PRODUCT OVERVIEW

What are pure copper balls?

Pure copper balls are soft, ductile metal spheres produced from high-conductivity copper such as C11000 ETP. Their electrical and thermal conductivity, formability and non-magnetic behavior distinguish them from harder copper alloys.

Copper is not a bearing material for high-load rolling contact. Purity, oxygen content, temper, surface oxidation and dimensional method should be matched to the electrical, thermal or decorative purpose.

TECHNICAL SPECIFICATIONS

Start with measurable requirements.

Values below are product-family references. The quotation, drawing, agreed standard and inspection plan control the final supply specification.

Technical itemReference specification

MaterialC11000 ETP copper or oxygen-free copper by agreement

Diameter RangeCustom range, typically 1–100 mm by method and quantity

Precision GradeCommercial / precision / custom-machined, depending on diameter

ToleranceControlled by the agreed precision grade, drawing or purchase specification

HardnessSoft metal; temper and process dependent

DensityApprox. 8.94 g/cm³

Surface FinishBright, polished, tumbled, plated or natural copper

Roundness / SphericityControlled according to the agreed precision grade and inspection method

Temperature ResistanceApplication, load, atmosphere and material-grade dependent

Chemical ResistanceConfirm exact fluid, concentration, temperature and exposure time

PackagingBulk, small-quantity, container, bag, carton, export pallet or customized packing

Electrical behaviorHigh conductivity; exact IACS requirement by grade

MagnetismNon-magnetic

OxidationNatural tarnish develops unless surface and packing are protected

PRODUCT SELECTION GUIDANCE

Compare materials before substituting.

Material selection affects load, wear, corrosion, temperature, precision, service life and total program cost.

Material optionPrimary advantageLimitationBest fit

Pure copperHighest conductivity and excellent ductilitySoft, easily marked and prone to oxidationElectrical, thermal and research uses

BrassBetter machinability and hardnessLower conductivityValves and custom hardware

Phosphor bronzeWear and fatigue resistanceLower conductivity and higher costElectrical springs and marine mechanisms

AluminumVery low density and good conductivity-to-weightLower conductivity by volume and different oxide behaviorLightweight electrical and aerospace work

KEY PERFORMANCE FEATURES

Performance that purchasing teams can verify.

Electrical conductivity

Supports contacts, current-transfer experiments and conductive assemblies.

Thermal transfer

High thermal conductivity suits heat-distribution and calibration concepts.

Ductile custom forming

Soft copper can be drilled, flattened, plated and finished for specialty parts.

Non-magnetic metal

Useful near magnets, sensors and specialized instruments.

TYPICAL APPLICATIONS

Specify the work the ball must perform.

Application names are starting points—not approval of universal suitability. Share the real medium, load, speed, pressure, temperature, life target and compliance needs.

Electrical contacts

Conductive spheres, switch elements and experimental current paths.

Thermal systems

Heat-transfer, calibration and research components.

Plating & electrochemistry

Copper feed, anode and process applications by purity requirement.

Art & design

Polished, patinated or plated spheres for visual programs.

Typical applications for Pure Copper Balls — REPRESENTATIVE APPLICATION ENVIRONMENTS

QUALITY & DOCUMENTATION

Build the evidence into the purchase order.

Document requirements should be defined before quotation so the inspection method, sampling level, traceability and external testing can be planned correctly.

Material identity or alloy / ceramic grade verified against the agreed purchase specification
Diameter, tolerance and geometry inspected using the method appropriate to the ordered precision level
Hardness, density, wall thickness or coating hardness tested when applicable to the product
Surface condition, finish and visual limits checked against approved samples or drawings
Roundness / sphericity or roller geometry inspected when specified
Lot identification and batch traceability maintained through controlled records
Material certificates and inspection reports available when agreed before quotation
Third-party testing, compliance documents and customer inspection plans supported by agreement

PACKAGING OPTIONS

Protect precision through delivery.

Final packing depends on material, diameter, surface sensitivity, order weight, storage time and destination.

Anti-tarnish inner packing

Sealed bags or protective paper selected for copper-alloy surface preservation.

Small-lot containers

Labeled bags, vials or trays for prototypes, repair and distributor orders.

Cartons, pails & drums

Industrial packing selected by diameter, total weight and handling method.

Customer-specific packing

Counted quantities, private labels, export pallets and corrosion protection by agreement.

Supported formats: bulk packaging · small-quantity packaging · plastic containers · bags · cartons · export pallets · customized packaging.

SMALL QUANTITY & SAMPLE ORDERS

Validate before you scale.

SDBALLS Industry Corp. supports North American customers with sample quantities, prototype requirements, testing programs and specialty ball inquiries.

State copper grade, conductivity requirement, diameter, temper, surface, oxidation tolerance and quantity. Handle samples with the same cleanliness expected in service.

PrototypeTestingRepairR&DSmall batch production

Request Samples ↗Contact U.S. Support

PRODUCT FAQ

Answers for engineering and purchasing teams.

Are copper balls suitable for bearings?

Generally no for conventional high-load bearings because copper is soft. They are selected mainly for conductivity, ductility and specialty contact.

What is the difference between ETP and oxygen-free copper?

They differ in oxygen content, conductivity behavior and suitability for vacuum, welding and electronic applications. Specify the required standard.

How can copper tarnish be controlled?

Sealed anti-tarnish packing, coatings, plating and controlled handling can reduce oxidation, but exposed copper naturally changes color.

Can copper balls be drilled or plated?

Yes. Holes, flats, threads, nickel plating and other custom work can be reviewed from a drawing.

Can you provide material certificates and inspection reports?

Yes. State the required certificate, inspection method, sampling plan and report format before quotation so documentation can be included in the supply plan.

Do you support samples and small-quantity orders?

Yes. SDBALLS Industry Corp. supports North American prototype, qualification, repair, R&D and small-batch requirements, subject to material, size and production availability.
